FT100-601/602 is a process indicator which accepts thermocouple, RTD and analog signals, the standard version works with TC/RTD inputs, and specify the analog inputs if the input is analog like 0-10VDC, 4-20mA etc, the display can be either in Celcius or Fahrenheit, maximum 3 alarms can be selected for large sizes, 24VDC auxiliary power supply is possible to power transduers like presure transmitters, process value can also be re-transmitted to feed to PLC or paperless recorders, RS-485 modbus communication available to be abled to connected with PLC and HMI

Maxwell MTC-V is VMD(valve motor drive) output temperature controller, incorporates 3-point stepping valve control feature, two relays, one control the open of the valve, one control the close of the valve, valve position indication, auto/manual control bumpless transfer, works with thermocouple, RTD, and analog inputs,

Maxwell DR04C is a din rail mount PID temperature controller, 2 channel configuration, works with TC/RTD inputs, and output can be Relay, SSR Drive, or analog like 4-20mA, 0-10VDC, 2 auxiliary outputs can be assigned as the alarm output for any of the channel, or it can also be configured as the cooling output, in some particular application, the auxiliary output can also be programmed as an event output which is controlled by a master device via RS-485 communication, the RS-485 is a standard features. 24VDC source to make sure greater safety. Modbus RTU or Modbus TCP/IP optional allows the integration with SCADA system smooth

IoT is getting more and more popular, to keep up with the trend, for some of temperature control system with PLC in it, we offer an alternative solution by using our DIN rail temperature controller plus our IoT box, or IoT HMI, the concept is implementing DIN rail temperature controller system and connect it with IoT HMI plus various I/O modulars, so that the PLC can be eliminated from the system,

Maxwell DR04D is a din rail mount PID temperature controller, 4 channel configuraitons, support thermocouple inputs(K,E,J,N,W,S,T,R,B), and output can be Relay, SSR Drive, or analog like 4-20mA, 0-10VDC, PID or ON/OFF control mode, RS-485 modbus communication as standard features, 24VDC source for greater saftey, auto/manual control switchable, when you have a sensor failure, the system can be quickly switched to manual control mode to maintain the temperature, soft-start and run/stop features.

Maxwell DR02B is a din rail mount PID temperature controller, 2 channel configuraitons, support thermocouple inputs(K,E,J,N,W,S,T,R,B), and output can be Relay, SSR Drive, it's a very simple din rail mount ccontroller, PID or ON/OFF control mode, RS-485 modbus communication as standard features, 85~265Vac source for easy system intergration, auto-tuning for both loops and with an external plug and play external configruation devices. the field configuration will be very easy to carry out.

The PT100-14 is a bolt-on PT100 Platinum Resistance Thermometer designed for direct surface temperature measurement. The sensor element is integrated into a ring (eye) terminal lug that is bolted or screwed directly onto the surface to be measured — such as a motor casing, heat sink, pipe outer wall, bearing housing, or structural component — ensuring intimate thermal contact without the need for a thermowell, probe pocket, or adhesive. This makes the PT100-14 an exceptionally convenient and cost-effective solution wherever surface temperature monitoring is required.

The ring terminal inner diameter is available in 6 mm or 8 mm as standard, and can be customised to match any bolt or screw size specified by the customer. The sensor is supplied with a stainless steel braided cable for mechanical protection and EMI shielding, and the lead wire material is fully selectable from stainless steel braid, silicone, fiberglass, or Teflon to suit the thermal and chemical conditions of the installation environment. Standard cable lengths are 2 m, 3 m, and 5 m, with custom lengths available on request. The sensor is available in temperature ranges up to 100 °C, 200 °C, or 300 °C.

FTX00-610 is a PID temperature controller with built-in timer, works with thermocuple and RTD inputs, relay output for timer, it's ability to maintain the tempearture at preset time duration is the key features of this item, when temperature reach to SV, the timer will be triggered automatically and starts to counting, when the time duration elapsed, a relay will pull-in and generate a dry contact signal. RS-485 modbus communication is optional, 24VDC/AC souce is optional as well.

The PT100-15 is a flexible, PFA-insulated RTD sensor engineered for precise temperature measurement in highly corrosive environments. Both the probe and cable are fully encapsulated in fluoropolymer (PFA), offering exceptional resistance to saline solutions, strong acids, caustic fluids, and electroplating baths. Designed for continuous immersion, the sensor’s flexibility allows for easy installation in confined or complex spaces, ensuring reliable performance in demanding industrial applications.

Maxwell DR04E is a din rail mount 4 input 4 relay outputs I/O modules, input can be dry contact or NPN input, 4 relay output can be controlled from master device like HMI or PLC, the input work independently apart from output, or the input can be programmed to work correlated with the output. 8 channel of timer incorporated.

FTX00-B612 is a PID temperature controller with built-in timer, what it does is pretty straight forward, for application with time and temperature invovled, the timer will most likely to kick-in when temperature reach the setting value, for example, the setting value is SV, the process starts at the ambient temperature and temperature goes up to setting value, when temperature reach setting value, the timer start to counting down or up and hold the temperature at the SV for a preset time duration. this is very useful and widely being used in equipments like water bath, sterilizer, beer brewing, power oven coating machine etc. the maixmum time range 9999 minutes

Maxwell DR8F-T-U06 is a din rail mount 8 input 8 transistor outputs I/O modules, input can be NPN or PNP input, 8 NPN transistor output can be controlled from master device like HMI or PLC, the input work independently apart from output.

Maxwell CP48T,CP72T,CP96T,CP49T is a 2 in1 temperature controller with timer, time and temperature are two variables that often involved in a heating relateble applications, a typical application such as heat press printing, food and beverage process, the timer and controller are actually two devices and built-in one

•8 channel AC current true RMS ammeter
•Din Rail mount, Can be used in temperature control system with to detect the True RMS current value
•24VDC source
•Maximum 400A measurement range

MTC-P ramp and soak PID profile multile steps controller is a advanced temperature controller, the process value changed based on predetermined ramping rate and soak rate. process value changes based on a curve over time, the output can be Relay to drive an AC contrator, or SSR Drive to drive an external solid state relay, or 4-20mA analog outputs, maximum 4 patterns with each pattern at maximum 8 segments, 4 pattern can be linked together as 1 program with 32 segements. this controller is suitable for application like muffle furnace, high temperature furnace, klin control etc.

MF43H is a touch screen ramp and soak controller, the conventional ramp and soak controllers or some call it profile controllers on the markets are configured via set buttons on the front panel. end user have to go through layers upon layers of parmaeters and navigate through different parameter during the configuration process. the process could be painful and stressed and often times lead to less efficient and frustration. the configuration with our touch screen ramp and soak controller is much more easier, it's easier for end user to pick up the process as they operate the controller like a cell phone. below are some of the basic features with this touch screen ramp and soak profile controller
