How to choose proper SCR power regulator according to your application ? SCR power regulator is heavily used in industrial application particularly heating application, to choose proper SCR, several key factors needs to be take into consideration.  1)first thing first, figure out your source whether it is single phase or three phase, the single phase SCR is for single phase source, 3 phase SCR is for 3 phase source, like 3 phase 4 wires, 3 phase 3 wires etc. if the load is single phase, the process is quite simple, make sure you select a SCR with the current rating 2 times higher of the actual load. for example, if you have a heater with 20 amps and 240Vac load, the proper SCR would be 40 amps and 240~480Vac load2)PIDMaxwell SCR power regulator only works for resistive load, make sure your load is resistive load like a heater, electric heater, infrared heater etc3)Identify your source, the source would be 3 phase 380V 4 wires source, like in China, or 3 phase 4 wire 400V in german...

ARAMP and Soak PID Controller is a specialized feedback control system designed to manage processes that require gradual changes (ramps) in a setpoint followed by stabilization periods (soaking). Unlike standard PID controllers that maintain a fixed setpoint, this controller dynamically adjusts the setpoint according to a predefined profile, ensuring smooth transitions between phases. Common in industries such as thermal processing, chemical manufacturing, and ceramics, it prevents system stress and improves process stability. Our MPU90 Series ramp and soak controller is a perfect choice. It has 0–25% FS accuracy and comes with PC software that records process values, setup values, and alarm events.   Key Features of a Good Ramp and Soak PID Controller: Accurate Setpoint Tracking: Accurately follows programmed ramp rates and soak durations, minimizing deviations even during dynamic changes. Smooth Transitions:Seamless changes between ramp and soak phases without abrupt outpu...

HART 7 is more than just a wireless protocol, our HART protocol temperature transmtiter TT-217 is HART 7 product, you can configure it by using our PC software or you can configure it by using standard HART communicator, the HART 7 standard applies to the full range of measurement, control, and automation systems products based on the HART Communication Protocol – whether wired or wireless. The WirelessHART capability is getting the most attention, but HART 7 provides many new capabilities beneficial to industry users in both wired and wireless products. Examples include: 1) Report by Exception—enables devices to push information to the control or asset management system without the system having to poll the device with a standard HART command. If there is a process or device status change, the device will automatically advise you.2) Time-Stamped Data—a valuable tool that adds a time stamp to process data readings sent to the host system which is helpful in evaluating...

Converting an old kiln into a more modern and efficient version involves several steps, depending on the specific features and condition of the existing kiln. Here is a general guide to help you get started: Assessment: Examine the current condition of the kiln, including its structure, insulation, heating elements, and control systems. Insulation Upgrade: Improve insulation to enhance energy efficiency. Modern insulating materials can help maintain consistent temperatures and reduce heat loss. Temperature Control: Upgrade the temperature control system to a more precise and programmable one. such as our MF43HYC  kiln controller, This may involve installing new thermocouples, and other modern temperature regulation equipment. Heating Elements: Check and replace outdated heating elements with more efficient ones. Consider using advanced materials for heating elements to achieve better performance and durability. Automation and Programmability: Integrate automation systems to contro...

Elevate Your Craft with Advanced Pottery Kiln Control Systems Introduction: In the intricate world of pottery, achieving perfection requires not just skillful hands but also precise control over the firing process. Enter the pottery oven controller – the unsung hero behind the scenes, ensuring that every piece of art emerges from the kiln in all its glory. In this guide, we'll delve into the importance of pottery oven controllers, their key features, and how investing in the right controller can elevate your pottery to new heights. Understanding Pottery Oven Controllers:Pottery oven controllers are the brains behind the firing process, regulating temperature, humidity, and other critical factors. Whether you're a seasoned artisan or a budding enthusiast, the right controller can make a significant difference in the outcome of your creations.Key Features to Look For:   Temperature Precision:Explore controllers with precise temperature regulation capabilities, ensuring that yo...

A Deep Dive into Kiln Controllers Introduction We are a PID temperature controller supplier in China, one of our kiln controller rolled out early of 2023 is very popular on the market and we are the first factory to introduce this kind of controller in China. Today we are going to dig deep into kiln controllers and beyond In the world of ceramics, pottery, and even certain industrial processes, the kiln plays a pivotal role in transforming raw materials into beautifully crafted and durable products. The key to achieving consistent and precise results lies in the heart of the kiln – its controller. In this blog, we'll explore the significance of kiln controllers, their functionalities, and how they contribute to achieving the perfect firing process. Understanding Kiln Controllers   A kiln controller is essentially the brain of the kiln. It is a sophisticated device designed to regulate the temperature, humidity, and other crucial factors during the firing process. Whether you...

There are a lot of old kiln made back in the days around the world where they have outdated analog controller, our MF43HYC touch screen kiln controller is a perfect solution to convert your old kiln into a 21st century PID controlled kiln, the touch screen makes it easy to create a firing plan for your kiln, you can do it on the device itself, Like Your Smartphone the new kiln controller navigates with just a touch of a finger and allows us to guide you through programming with full sentences, helpful icons, and dynamic navigation. If that is not easy enough for you, you can access to the controller remotely from your cellphone or PC and program it on your cell phone and PC, or we can access the controller remotely from here in China to help your with the programming from China even if you are in different country as long as you have the internet access, another valuable addition is the datalogging  feature where you can download data to your PC for future analysis purpose. You do...

What can power regulators be used for? we are going to cover this topic today. Power regulators can be widely used in the following areas: 1. Electric furnace industry: annealing furnace, drying furnace, quenching furnace, sintering furnace, crucible furnace, tunnel furnace, melting furnace 2. Machinery and equipment: packaging machinery, injection molding machinery, heat shrink machinery, kneading machinery, food machinery, tempering equipment, plastic processing, infrared heating 3. Glass industry: glass fiber, glass molding, glass melting, glass printing, float glass production line, annealing tank 4. Automobile industry: spray drying, thermoforming 5. Energy-saving lighting: tunnel lighting, street lighting, photography lighting, stage lighting 6. Chemical industry: distillation and evaporation, preheating system, pipeline heating, petrochemical industry, temperature compensation.

The powder coating oven requires precise control on both temperature and time, the typical process would be hold the temperature and a set value for a certain period of time, the conventional solution would be using two control device , one is a temperature controller and the other one is a timer. At Maxwell, we have a temperature controller with built-in timer, the temperature can be controlled at a preset value and the timer can be programmed to engaged when temperature reach to set value and holding the temperature at certain period of time, when the time elapsed, the burner will be turned off. our model FT20X is a perfect solution for the oven. when the coating process finished, operator can hear a buzzer goes off to sort of notify the process is finished.
