3 digits display LED display programmable timer

● Digital programmable timer● 48mm*48mm, LCD display,6 digits● Display format,00.00.00, seconds,minutes,hours● Panel mount type● Dry contact, NPN input● Maximum 4 outputs(Relay or SSR Drive)● 85~265Vac or 24VDC source

● Digital programmable timer+counter,● 48mm*48mm,Dual line 4 digits display● 2 in1 timer+counter● Various timer triggering mode● OP1 output for timer and OP2 output for counter● 85~265Vac or 24VDC source● Perfect solution for application need timer and counter

● Digital programmable counter● 48mm*48mm,Dual line 4 digits display● Panel mount type● Dry contact, NPN input● Maximum 2 outputs(OP1 and OP2)● 85~265Vac or 24VDC source● SV counting/Batch counting/Totalizing count

● Digital programmable counter● Dual line 6 digits LCD display● Panel mount type● Dry contact, NPN input● Maximum 4 outputs(OP1 and OP2)● 85~265Vac or 24VDC source● SV counting/Batch counting/Totalizing count

The PT100-5 is a compact and versatile probe-type Platinum Resistance Thermometer (PT100 RTD) featuring a stainless steel sensing tube without screw fittings. This design makes it an ideal choice for applications where the sensor is inserted directly into a thermowell, clamped in place, or embedded within equipment — offering a clean, low-profile installation without the need for threaded process connections. The PT100-5 is fully waterproof, making it well suited for wet or humid environments. Lead wire material and length are fully customisable, and the sensor is available in three probe diameters and multiple probe lengths to accommodate a wide range of installation geometries. Its straightforward construction and broad compatibility make it a popular choice for both OEM integration and field replacement applications.

The PT100-8 is a probe-type Platinum Resistance Thermometer (PT100 RTD) distinguished by its adjustable insertion depth — a key feature that sets it apart from fixed-length sensors. A stainless steel compression fitting is integrated into the assembly, forming a liquid-tight or pressure-tight seal against the process wall while allowing the operator to slide and lock the probe at any desired insertion depth before or after installation. This eliminates the need to specify a fixed immersion length at the time of ordering and greatly simplifies retrofitting into existing equipment. The probe is constructed from 304 stainless steel and is available in diameters of 4 mm, 5 mm, and 6 mm. The lead cable is shielded with a metal braid and covered with PTFE insulation, delivering low noise, high mechanical strength, and excellent resistance to elevated temperatures. The PT100-8 is compatible with a wide range of process fittings — including NPT, BSP, and metric threads — and is available in a waterproof configuration, making it suitable for measuring the temperature of both air and liquids across diverse industrial environments.

The KFY-002 is a compact, waterproof thermocouple and RTD connection head (terminal box) designed for reliable field installation in demanding industrial environments. Featuring an aesthetically pleasing die-cast body with a brilliant, durable paint finish available in grey and yellow, the KFY-002 combines robust protection with ease of use. The spacious internal cavity provides ample room for comfortable, tool-free wiring, significantly reducing installation time. The standardised internal height of H = 33 ± 0.1 mm ensures full compatibility with internationally sourced terminal blocks and signal converters, enabling seamless integration into global instrumentation systems. The KFY-002 is designed to accommodate virtually all common sensor configurations: standard thermocouples, PT100/PT1000 thermal resistors, armoured (mineral-insulated) thermocouples and RTDs, as well as sensors fitted with integrated temperature transmitters. A stainless steel safety chain secures the lid against accidental loss during maintenance.

MTC-P ramp and soak PID profile multile steps controller is a advanced temperature controller, the process value changed based on predetermined ramping rate and soak rate. process value changes based on a curve over time, the output can be Relay to drive an AC contrator, or SSR Drive to drive an external solid state relay, or 4-20mA analog outputs, maximum 4 patterns with each pattern at maximum 8 segments, 4 pattern can be linked together as 1 program with 32 segements. this controller is suitable for application like muffle furnace, high temperature furnace, klin control etc.
