Three-Phase Intelligent SCR Power Regulator

The Maxwell TC-200S Series is an industrial-grade, three-phase intelligent SCR (Silicon Controlled Rectifier) power regulator designed for precise, stepless control of resistive heating loads in demanding industrial environments. Manufactured by Maxwell Automation Technology Co., Ltd. under the PIDMaxWell brand, the TC-200S combines a fully digital control architecture with an integrated dual-row LED display, multi-function indicator LEDs, and a front-panel keypad, enabling operators to monitor process parameters and adjust output settings directly without external programming tools.

The regulator accepts a wide range of analogue control input signals — including 4–20 mA, 0–20 mA, 0–5 VDC, 0–10 VDC, 1–5 VDC, and 2–10 VDC — and features automatic phase detection, making it straightforward to integrate into new or existing control systems. An integrated soft-start (ramp) function eliminates inrush current surges at power-on, protecting both the SCR modules and the connected heating elements from thermal shock. When the heat-sink temperature exceeds the user-defined alarm threshold (AL1), the unit automatically reduces output power to a configurable safe level (EOP), maintaining process continuity while safeguarding the internal SCR modules from thermal damage.

An optional RS-485 communication interface with Modbus-RTU protocol enables seamless integration into SCADA systems, PLCs, DCS, and industrial IoT networks. The TC-200S supports auto/manual bumpless transfer, run/stop control, and configurable minimum and maximum output limits, providing the flexibility required for a wide range of industrial heating and process control applications. Rated current options of 100 A, 125 A, 150 A, 175 A, 200 A, and 225 A cover load capacities from 48 kW to 190 kW (three-phase), making the TC-200S suitable for small laboratory ovens through to large industrial electric furnaces.
